Copper Clad Aluminum Flexible Electrical Wire
Structure
Conductor: Copper-clad aluminum (CCA), fine stranded flexible conductor
Insulation: PVC (polyvinyl chloride)
Color: black / red / blue / green / yellow / double color (yellow-green)
Characteristic
|
Rated voltage |
450/750V |
|
Long-term allowable temperature |
The permissible operating temperature of the cable should not exceed 70℃. |
|
Certification |
CE |
Why choose Copper Clad Aluminum flexible electrical wire?
Up to 30% Cost Savings as Copper Prices Rise
With copper prices projected to reach USD 15,000/ton by 2026, Copper Clad Aluminum flexible wire helps control material costs and protect project margins compared with pure copper.Copper-Equivalent Performance for Standard Loads
Copper-Equivalent Performance
Stable conductivity for standard electrical loads, reducing performance and compliance risks.
Flexible & Easy to Install
Fine-stranded Copper Clad Aluminum conductor improves flexibility and ensures stable transmission during bending.
Built for Cost-Controlled Projects
Ideal for equipment wiring, OEM manufacturing, and commercial electrical systems.
FAQ
-
Q1: What is Copper Clad Aluminum flexible electrical wire?
-
Q2: Is Copper Clad Aluminum flexible wire as good as copper flexible wire?
-
Q3: Is Copper Clad Aluminum flexible electrical wire safe to use?
-
Q4: What certifications does Copper Clad Aluminum flexible electrical wire have?
-
Q5: Can Copper Clad Aluminum flexible electrical wire be used outdoors?
Specification
| No. Cross-section of conductor |
Rated voltage | Conductor structure |
Insulation thickness | Sheath thickness | Cable outer diameter |
Max. D.C resistance of conductor at 20 ℃ |
| mm2 | V | N/mm | mm | mm | mm | Ω /km |
| 1.5 | 450/750 | 35/0.260 | 0.70 | / | 3.18 | 13.3 |
| 2.5 | 450/750 | 58/0.260 | 0.80 | / | 3.89 | 7.98 |
| 4 | 450/750 | 66/0.310 | 0.80 | / | 4.51 | 4.95 |
| 6 | 450/750 | 99/0.310 | 0.80 | / | 5.16 | 3.3 |
| 10 | 450/750 | 99/0.410 | 1.00 | / | 6.71 | 1.91 |
